Aluminum Sheet Stock Sizes
| Thickness/mm | Size/mm | |||
| 0.5 | 0.6 | 0.8 | 1 | 1250x2500 1500x3000 1520x3020 |
| 1.2 | 1.5 | 2 | 2.5 | |
| 3 | 4 | 5 | 6 | |
Aluminum plate Stock Sizes
| Thickness/mm | Size/mm | ||||||
| 8 | 10 | 12 | 14 | 15 | 16 | 18 | 1250x2500 1500x3000 1520x3020 1525x3660 2000x4000 2400x4000 |
| 20 | 22 | 25 | 28 | 30 | 35 | 40 | |
| 45 | 50 | 55 | 60 | 65 | 70 | 75 | |
| 80 | 85 | 90 | 95 | 100 | 110 | 120 | |
| 130 | 140 | 150 | 160 | 170 | 180 | 190 | |
| 200 | 210 | 220 | 230 | 240 | 250 | 260 | |
Aluminum cast plate Stock Sizes
| Thickness/mm | Size/mm | |||
| 100 | 150 | 200 | 250 | Can be sawed Can be precision ground |
| 300 | 350 | 400 | 450 | |
| 500 | 550 | 600 | Can be customized | |
Aluminum forged Plate Stock Sizes
| Thickness/mm | Size/mm | ||||||
| 250 | 260 | 270 | 280 | 290 | 300 | 310 | 1520*2500 1520*3020 |
| 320 | 330 | 340 | 350 | 370 | 380 | 390 | |
| 400 | 410 | 420 | 430 | 440 | 450 | 460 | |
| 470 | 480 | 490 | 500 | 510 | 520 | 530 | |
| 540 | 550 | 560 | 570 | 580 | 590 | 600 | |
Don't see the aluminum plate size you need in our stock range? Check out the custom aluminum plate sizes below or contact our aluminum plate experts.Contact us
Chalco's Hot-Rolled Aluminum Plate Production Range
| Alloy | Temper | Dimension(mm) | Executive Standard | ||
| Thickness | Width | Length | |||
| Series 1, 3, 8 | O, F, H111, H112, H12, H14, H16, H18, H19, H22, H24, H26 |
0.2~0.5 | 500~1500 | 500~4000 | ASTM B209 ASME SB-209 EN 485 YS/T91 GB/T3880 |
| 0.6~4.0 | 1000~2650 | 2000~10000 | |||
| 4.1~12.0 12.1~20 21~200 | 1000~2650 1000~3800 1000~3800 |
2000~20000 | |||
| Series 5 | O, F, H111, H112, H12, H14, H16, H18, H19, H22, H24, H26, H28, H32, H34, H36, H38, H116, H321 |
0.2~0.5 0, 6~4, 0 | 1000~1500 1000~2650 |
2000~10000 | ASTMB209 ASME SB-209 EN485 ASTMB928M GB/T3880 GJB1541 GJB2662 |
| 4.1~12.0 12.1~20 21~200 | 1000~2650 1000~3800 1000~3800 |
2000~20000 | |||
| Series 2, 6, 7 | O, F, H111, H112, T3, T4, T6, T7 |
0.3~0.7 0.8~2.0 2.1~12.0 | 1000~1500 1000~2650 1000~2650 |
2000~10000 | ASTM B209 ASME SB-209 EN 485 GB/T3880 GJB1541 GB/T167 GJB2053 GJB2662 |
| 12.1~20 21~200 | 1000~3800 1000~3800 |
2000~20000 | |||
| T351, T451, T651, T851, T7451, T74, T87 |
5.0~12.0 | 1000~2650 | 2000~10000 | GJB1741 | |
| 12.1~20 | 1000~3800 | 2000~20000 | |||
