5083 aluminum metal plate, an AL - Mg alloy, holds the title of the most widely used rust - proof aluminum. This alloy is revered for its high strength, particularly in terms of fatigue strength. It also boasts high plasticity and remarkable corrosion resistance. Notably, it can achieve quite high strength through work hardening without the need for heat treatment. Its corrosion resistance to the ocean and atmosphere is excellent, and it offers good welding performance and other superior properties.
If you're in the market for bulk purchases of 5083 aluminum plate, SINOATF is your go - to source. We can customize products to meet your specific specifications, including American and European standards. For detailed information, you can refer to our 5083 aluminum sheet size and performance specifications.
-
Specification: ASTM B209, EN 485, AMS 4056, AMS - QQ - A - 250/6
-
Application: Cryogenic Storage Tanks, LNG Storage Tanks, Pressure Vessels
| Description |
Thickness/in |
Size/in |
Description |
Thickness/in |
Size/in |
| 5083 O aluminum plate |
0.1250" |
60"x144" |
5083 O aluminum plate |
0.6250" |
96"x288" |
| 5083 O aluminum plate |
0.2500" |
96"x240" |
5083 O aluminum plate |
0.7500" |
96"x288" |
| 5083 O aluminum plate |
0.3750" |
96"x288" |
5083 O aluminum plate |
0.7500" |
96"x240" |
| 5083 O aluminum plate |
0.3750" |
120"x240" |
5083 O aluminum plate |
1.0000" |
120"x240" |
| 5083 O aluminum plate |
0.3750" |
60"x144" |
5083 O aluminum plate |
1.0000" |
96"x288" |
| 5083 O aluminum plate |
0.3750" |
72"x190" |
5083 O aluminum plate |
1.0000" |
72"x240" |
| 5083 O aluminum plate |
0.5000" |
96"x288" |
5083 O aluminum plate |
1.0000" |
96"x240" |
| 5083 O aluminum plate |
0.5000" |
120"x240" |
5083 O aluminum plate |
1.2500" |
60"x144" |
| 5083 O aluminum plate |
0.5000" |
72"x240" |
5083 O aluminum plate |
1.5000" |
120"x240" |
| 5083 O aluminum plate |
0.5000" |
120"x288" |
5083 O aluminum plate |
1.7500" |
96"x288" |
| 5083 O aluminum plate |
0.6250" |
96"x288" |
5083 O aluminum plate |
2.0000" |
96"x288" |
-
Specification: ASTM B928, EN 485, AMS - QQ - A - 250/6
-
Standard Thicknesses: 0.125", 0.25", 0.375", Thicker aluminum plates provide better durability for hulls.
-
Standard Dimensions: 60" x 120", suitable for various applications.
-
Typical Ship Plate Dimensions: 96" x 240" and 96" x 288", meeting the demand for longer specifications in marine aluminum plates.
-
Certification: Available from classification societies such as CCS, BV, LR, ABS, KR, DNV, RINA, and PC.
| Description |
Thickness/in |
size/in |
Description |
Thickness/in |
size/in |
| 5083 H116 aluminum plate |
1/8" |
96"x240" |
5083 H321 aluminum plate |
1" |
96"x240" |
| 5083 H116 aluminum plate |
3/16" |
96"x240" |
5083 H321 aluminum plate |
1 1/4" |
96"x240" |
| 5083 H116 aluminum plate |
1/4" |
96"x240" |
5083 H321 aluminum plate |
1 1/2" |
96"x240" |
| 5083 H116 aluminum plate |
5/8" |
96"x240" |
5083 H321 aluminum plate |
2" |
96"x240" |
| 5083 H116 aluminum plate |
3/4" |
96"x240" |
5083 H321 aluminum plate |
2 1/2" |
96"x240" |
| 5083 H116 aluminum plate |
1" |
96"x240" |
5083 H321 aluminum plate |
3" |
96"x240" |
| 5083 H116 aluminum plate |
1 1/4" |
96"x240" |
5083 H321 aluminum plate |
3 1/4" |
96"x240" |
| 5083 H116 aluminum plate |
1 1/2" |
96"x240" |
5083 H321 aluminum plate |
3 1/2" |
96"x240" |
| 5083 H116 aluminum plate |
2" |
96"x240" |
5083 H321 aluminum plate |
4" |
60"x120" |
| 5083 H321 aluminum plate |
1/4" |
96"x240" |
5083 H321 aluminum plate |
4 1/4" |
60"x120" |
| 5083 H321 aluminum plate |
5/8" |
96"x240" |
5083 H321 aluminum plate |
4 1/2" |
60"x120" |
| 5083 H321 aluminum plate |
3/4" |
96"x240" |
5083 H321 aluminum plate |
6" |
60"x120" |
-
Specification: MIL - DTL - 46027, ASTM B209, AMS - QQ - A - 250/6
-
Application: Naval Vessels, Tank Armor Plates, Armored Personnel Carriers (APC)
-
Note: For 5083 H131 aluminum armor plates with thicknesses exceeding 0.499”, ballistic reports can be provided upon customer request.
| Description |
Temper |
Thickness/in |
Size/in |
Spec |
| 5083 H131 Aluminum Armor Plate |
H131 |
1.25" |
72"X144" |
MIL – DTL – 46027k |
| 5083 H131 Aluminum Armor Plate |
H131 |
1.5" |
72"X144" |
MIL – DTL – 46027k |
| 5083 H131 Aluminum Armor Plate |
H131 |
1.75" |
72"X144" |
MIL – DTL – 46027k |
| 5083 H131 Aluminum Armor Plate |
H131 |
2" |
72"X144" |
MIL – DTL – 46027k |
| 5083 H131 Aluminum Armor Plate |
H131 |
2.25" |
72"X144" |
MIL – DTL – 46027k |
| 5083 H131 Aluminum Armor Plate |
H131 |
2.5" |
72"X144" |
MIL – DTL – 46027k |
| 5083 H131 Aluminum Armor Plate |
H131 |
3" |
72"X144" |
MIL – DTL – 46027k |
| 5083 H32 Aluminum Armor Plate |
H32 |
0.25" |
48"X144" |
ASTM B209 |
| 5083 H32 Aluminum Armor Plate |
H32 |
0.5" |
48"X144" |
ASTM B209 |
| 5083 H32 Aluminum Armor Plate |
H32 |
0.75" |
48"X144" |
ASTM B209 |
| 5083 H32 Aluminum Armor Plate |
H32 |
1" |
48"X144" |
ASTM B209 |
| 5083 H32 Aluminum Armor Plate |
H32 |
1.25" |
48"X144" |
ASTM B209 |
| 5083 H32 Aluminum Armor Plate |
H32 |
1.5" |
48"X144" |
ASTM B209 |
| 5083 H32 Aluminum Armor Plate |
H32 |
1.75" |
48"X144" |
ASTM B209 |
| 5083 H32 Aluminum Armor Plate |
H32 |
2" |
48"X144" |
ASTM B209 |
| 5083 H32 Aluminum Armor Plate |
H32 |
2.25" |
48"X144" |
ASTM B209 |
| 5083 H32 Aluminum Armor Plate |
H32 |
2.5" |
48"X144" |
ASTM B209 |
| 5083 H32 Aluminum Armor Plate |
H32 |
3" |
48"X144" |
ASTM B209 |
| 5083 H32 Aluminum Armor Plate |
H32 |
3.25" |
48"X144" |
ASTM B209 |
| 5083 H32 Aluminum Armor Plate |
H32 |
3.5" |
48"X144" |
ASTM B209 |
| 5083 H32 Aluminum Armor Plate |
H32 |
4" |
48"X144" |
ASTM B209 |
-
Specification: EN 485, AMS - QQ - A - 250/6
-
Application: Tank Car Heads/Bodies/Baffles, LNG storage tanks
| Description |
Thickness(mm) |
size/mm |
Description |
Thickness(mm) |
size/mm |
| 5083 H111 sheet |
1 |
1250x2500 |
5083 H111 sheet |
6 |
1250x2500 |
| 5083 H111 sheet |
1 |
1500x3000 |
5083 H111 sheet |
6 |
1500x3000 |
| 5083 H111 sheet |
1.5 |
1250x2500 |
5083 H111 plate |
16 |
2000x4000 |
| 5083 H111 sheet |
1.5 |
1500x3000 |
5083 H111 plate |
18 |
2000x4000 |
| 5083 H111 sheet |
2 |
1250x2500 |
5083 H111 plate |
30 |
2000x4000 |
| 5083 H111 sheet |
2 |
1500x3000 |
5083 H111 plate |
35 |
2000x4000 |
| 5083 H111 sheet |
2.5 |
1500x3000 |
5083 H111 plate |
40 |
2000x4000 |
| 5083 H111 sheet |
2.95 |
1500x3000 |
5083 H111 plate |
45 |
2000x4000 |
| 5083 H111 sheet |
3 |
1250x2500 |
5083 H111 plate |
55 |
2000x4000 |
| 5083 H111 sheet |
3 |
1500x3000 |
5083 H111 plate |
65 |
2000x4000 |
| 5083 H111 sheet |
4 |
1250x2500 |
5083 H111 plate |
70 |
2000x4000 |
| 5083 H111 sheet |
4 |
1500x3000 |
5083 H111 plate |
80 |
2000x4000 |
| 5083 H111 sheet |
5 |
1250x2500 |
5083 H111 plate |
90 |
2000x4000 |
| 5083 H111 sheet |
5 |
1500x3000 |
5083 H111 plate |
110 |
2000x4000 |
-
Specification: ASTM B209, EN 485, AMS - QQ - A - 250/6
| Description |
Thickness(mm) |
Size(mm) |
Description |
Thickness(mm) |
Size(mm) |
| 5083 H112 sheet |
4 |
1500x3000 |
5083 H112 plate |
50 |
2000x4000 |
| 5083 H112 sheet |
5 |
1500x3000 |
5083 H112 plate |
50 |
1500x3000 |
| 5083 H112 sheet |
6 |
1500x3000 |
5083 H112 plate |
55 |
1500x3000 |
| 5083 H112 plate |
8 |
1500x3000 |
5083 H11 |
|
