3003 Aluminum Sheet is a typical AL - Mn series alloy known for its excellent workability, weldability, and corrosion resistance. Although it can't be strengthened by heat treatment, its mechanical properties can be improved through cold working methods.
For bulk purchases, SINOATF can customize according to your requirements for American or European standards. You can view the specifications and performance details for 3003 aluminum sheets.
SINOATF's best - selling sizes for A93003 aluminum sheets
SINOATF offers a variety of hot - selling sizes for AL3003 aluminum sheets, which can be customized or cut. The most popular are AMS 4006 in the O state and AMS 4008 in H14.
SINOATF offers a variety of hot - selling sizes for AL3003 aluminum sheets, which can be customized or cut. The most popular are AMS 4006 in the O state and AMS 4008 in H14.
| Description | Temper | Thickness/in | Width*Length/in |
| 0.016(t) 3003 H14 Aluminum sheet AMS 4008 ASTM B209 48x96 | H14 | 0.016 | 48x96 |
| 0.02(t) 3003 H14 Aluminum sheet AMS 4008 ASTM B209 48x96 | H14 | 0.02 | 48x96 |
| 0.025(t) 3003 H14 Aluminum sheet AMS 4008 ASTM B209 48x120 | H14 | 0.025 | 48x120 |
| 0.032(t) 3003 H14 Aluminum sheet AMS 4008 ASTM B209 48x120 | H14 | 0.032 | 48x120 |
| 0.032(t) 3003 H14 Aluminum sheet AMS 4008 ASTM B209 48x144 | H14 | 0.032 | 48x144 |
| 0.04(t) 3003 H14 Aluminum sheet AMS 4008 ASTM B209 48x120 | H14 | 0.04 | 48x120 |
| 0.04(t) 3003 H14 Aluminum sheet AMS 4008 ASTM B209 48x144 | H14 | 0.04 | 48x144 |
| 0.05(t) 3003 H14 Aluminum sheet AMS 4008 ASTM B209 60x120 | H14 | 0.05 | 60x120 |
| 0.05(t) 3003 H14 Aluminum sheet AMS 4008 ASTM B209 60x144 | H14 | 0.05 | 60x144 |
| 0.063(t) 3003 H14 Aluminum sheet AMS 4008 ASTM B209 48x96 | H14 | 0.063 | 48x96 |
| 0.063(t) 3003 H14 Aluminum sheet AMS 4008 ASTM B209 48x120 | H14 | 0.063 | 48x120 |
| 0.063(t) 3003 H14 Aluminum sheet AMS 4008 ASTM B209 48x144 | H14 | 0.063 | 48x144 |
| 0.08(t) 3003 H14 Aluminum sheet AMS 4008 ASTM B209 48x96 | H14 | 0.08 | 48x96 |
| 0.08(t) 3003 H14 Aluminum sheet AMS 4008 ASTM B209 48x144 | H14 | 0.08 | 48x144 |
| 0.09(t) 3003 H14 Aluminum sheet AMS 4008 ASTM B209 48x96 | H14 | 0.09 | 48x96 |
| 0.1(t) 3003 H14 Aluminum sheet AMS 4008 ASTM B209 48x120 | H14 | 0.1 | 48x120 |
| 0.1(t) 3003 H14 Aluminum sheet AMS 4008 ASTM B209 48x144 | H14 | 0.1 | 48x144 |
| 0.125(t) 3003 H14 Aluminum sheet AMS 4008 ASTM B209 48x96 | H14 | 0.125 | 48x96 |
| 0.125(t) 3003 H14 Aluminum sheet AMS 4008 ASTM B209 48x120 | H14 | 0.125 | 48x120 |
| 0.125(t) 3003 H14 Aluminum sheet AMS 4008 ASTM B209 48x144 | H14 | 0.125 | 48x144 |
| 0.125(t) 3003 H14 Aluminum sheet AMS 4008 ASTM B209 36x120 | H14 | 0.125 | 36x120 |
| 0.125(t) 3003 H14 Aluminum sheet AMS 4008 ASTM B209 60x144 | H14 | 0.125 | 60x144 |
| 0.19(t) 3003 H14 Aluminum plate AMS 4008 ASTM B209 48x144 | H14 | 0.19 | 48x144 |
| 0.25(t) 3003 H14 Aluminum plate AMS 4008 ASTM B209 48x120 | H14 | 0.25 | 48x120 |
| 0.25(t) 3003 H14 Aluminum plate AMS 4008 ASTM B209 48x144 | H14 | 0.25 | 48x144 |
| 0.32(t) 3003 H14 Aluminum plate AMS 4008 ASTM B209 48x120 | H14 | 0.32 | 48x120 |
| 0.32(t) 3003 H14 Aluminum plate AMS 4008 ASTM B209 48x144 | H14 | 0.32 | 48x144 |
| 0.375(t) 3003 H14 Aluminum plate AMS 4008 ASTM B209 48x120 | H14 | 0.375 | 48x120 |
| 0.04(t) 3003 O Aluminum sheet AMS4006 ASTM B209 48x144 | O | 0.04 | 48x144 |
| 0.09(t) 3003 O Aluminum sheet AMS4006 ASTM B209 48x144 | O | 0.09 | 48x144 |
| 0.05(t) 3003 O Aluminum sheet AMS4006 ASTM B209 48x144 | O | 0.05 | 48x144 |
| 0.63(t) 3003 O Aluminum sheet AMS4006 ASTM B209 48x144 | O | 0.63 | 48x144 |
SINOATF 3003 aluminum sheet specifications
| Name | 3003 aluminum sheet | |
| Hot selling status | O, H22, H24, H14, H16, H26, H18, H28, H112 | |
| Equivalent name | AW-AlCu4Mg1, 3.0517, A93003, AlCu4Mg, AlCuMg2, ASTM B209 | |
| 3003 aluminum sheets | Thickness:0.01”-0.24”(0.2mm-6mm) | Width:35.4”-104”(900mm-2650mm) |
| 3003 aluminum plate | Thickness:0.32”-9.84”(8mm-250mm) | Width:35.4”-104”(900mm-2650mm) |
| 3003 Ultra wide aluminum sheet | Thickness:0.01”-0.24”(0.2mm-6mm) | Width:35.4”-104”(900mm-2650mm) |
| 3003 white coated aluminum sheet | Thickness:0.01”-0.24”(0.2mm-6mm) | Width:35.4”-104”(900mm-2650mm) |
| 3003 aluminum diamond plate | Thickness:0.05”0.32”(1.2-8mm) | Width:35.4”-72.83”(900mm-1850mm) |
| length | Max 6m, Fix & Cut Length or Customized | |
| Surface treatment | Mill finish, Bright, polished, hair line, brush, sand blast, checkered, embossed, etching, etc. | |
| Lamination type | Blue film, transparent film, black and white film, paper (film thickness: 50 microns, 80 microns) | |
| Standard | AMS 4008, ASTM B20, QQ-A-250/2, ASTM B209, AMS4006 | |
SINOATF EN-AW3003 aluminum plate physical properties
| 3003-O | 3003-H14 | 3003-H22 | |
| Shear Strength | 75MPa | 96MPa | 81MPa |
| Tensile Strength | 40-110MPa | 130-160MPa | 94-140MPa |
| Elastic Modulus | 70GPa | 70GPa | 70GPa |
| Hardness Brinell | 28HB | 42HB | 37HB |
| Elongation | 28% | 8% | 8% |
Questions you might have about 3003 aluminum plate
Popular options for Sinoatf's 3003 aluminum sheets
- AA3003-O Annealed Aluminum Sheet:Suitable for deep drawing with excellent anodizing effects.
- AL3003-H14 Aluminum Sheet: Features good rust resistance.
- A93003-H22 H26 Aluminum Sheet: High corrosion resistance, offering a long service life.
- Hot-rolled ASTM B209 3003 Aluminum Sheet: Exhibits good deep drawing and elongation properties.
- 3003 Ultra-wide Aluminum Sheet: Up to 2650mm in width, suitable for aluminum roofing and box car skins.
- EN-AW3003 Oxidized Aluminum Sheet:Exceptional oxidation effects, used for high-end applications like rice cooker linings, baking molds, etc.
- 3003 Aluminum Foil Rolls:Utilized in honeycomb core, electronic foils, container foils, and similar applications.
- 3003 Deep Drawing Aluminum Sheet: In O condition, it's used to press into 3003 aluminum discs for making cookware, traffic signs, etc.
- 3003 Color-coated Aluminum Sheet:High flatness and excellent color coating, suitable for roofing materials, corrugated sheets, soundproof ceiling panels, etc.
